F03 FRAME
| Číslo na výkresu |
Název součástky Kód součástky |
Sklad | Cena | ||
|---|---|---|---|---|---|
| 01 | PRESS PLATE, BATTERY 9AWA-030201 | Skladem | 139,83 Kč | ||
| 02 | RUBBER WASHER, BATTERY 9010-030005 | Skladem | 15,54 Kč | ||
| 03 | FRAME 9AWA-031000-G0000 | Skladem | |||
| 03 | FRAME ASSY 9AWA-031000-H0000 | Skladem | |||
| 03 | Hlavní rám X850/X1000 9AWA-031000-F0000 | Skladem | 66 589,01 Kč | ||
| 04 | BRACKET, REAR HEAT INSULATION 9AWA-030001 | Skladem | |||
| 04 | REAR HEAT INSULATION PLATE BRACKET 9AWA-030001-10000 | Skladem | 77,68 Kč | ||
| 05 | BUSHING, FRONT GEAR CASE 9AWA-030002 | Skladem | 62,15 Kč | ||
| 06 | UPPER BRACKET, FRONT GEAR CASE 9AWA-037000 | Skladem | 326,26 Kč | ||
| 07 | BRACKET, BATTERY 9AWA-039101-10000 | Skladem | 326,26 Kč | ||
| 08 | UPPER BRACKET, REAR GEAR CASE 9AWA-033000-10000 | Skladem | 497,16 Kč | ||
| 09 | BRACKET ASSY., FOOTREST PEDAL(LH) 9AWA-035000 | Skladem | 1 398,28 Kč | ||
| 10 | BRACKET ASSY., FOOTREST PEDAL(RH) 9AWA-034000 | Skladem | 1 398,28 Kč | ||
| 11 | FRONT MOUNT PLATE(LH), ENGINE 9AWA-030003 | Skladem | 93,22 Kč | ||
| 12 | FRONT MOUNT BRACKET, ENGINE 9AWA-030004 | Skladem | 139,83 Kč | ||
| 13 | FRONT MOUNT PLATE(RH), ENGINE 9AWA-030005 | Skladem | 93,22 Kč | ||
| 14 | BRACKET, PARKING CABLE 9AWA-038000 | Skladem | 108,75 Kč | ||
| 15 | BRACKET, HEAD GUARD 9AWA-030120-10000 | Skladem | 232,13 Kč | ||
| 16 | LH PANEL, SEMIAXIS 9AWA-030006 | Skladem | 155,36 Kč | ||
| 17 | RUBBER SLEEVE, REAR SEAT 7020-130001 | Skladem | 62,15 Kč | ||
| 18 | RH PANEL, SEMIAXIS 9AWA-030007 | Skladem | 155,36 Kč | ||
| 19 | NUT M10x1.25 30204-102810 | Skladem | 15,54 Kč | ||
| 20 | NUT M8 30204-080810 | Skladem | 15,54 Kč | ||
| 21 | BRACKET, FLASHER 7020-230003 | Skladem | |||
| 22 | Šroub 30006-102020810 | Skladem | 43,52 Kč | ||
| 23 | BOLT M6x16 30006-060016810 | Skladem | 15,54 Kč | ||
| 24 | BOLT M8x20 30006-080020810 | Skladem | 15,54 Kč | ||
| 25 | BOLT M6x12 30006-060012810 | Skladem | 15,54 Kč | ||
| 26 | DAMPER, FUEL TANK 9AWA-120001-00001 | Skladem | 46,61 Kč | ||
| 27 | SPONGE PAD, FUEL TANK 9010-120008 | Skladem | 31,07 Kč | ||
| 28 | SPONGE, FRONT TOP COVER 4020-040402 | Skladem | 15,54 Kč | ||
| 29 | RUBBER CUSHION, MAIN STAND 5190-001003 | Skladem | 15,54 Kč | ||
| 30 | BRACKET ASSY, WINCH CONTROLLER 9AWA-039300 | Skladem | |||
| 31 | CONVERTING BRACKET, ECU 9AWA-030030 | Skladem | |||
| 32 | BRACKET, IGNITION COIL 9AWA-030060-20000 | Skladem | 145,08 Kč | ||
| 33 | BRACKET, REGULATOR 9AWA-030070 | Skladem | |||
| 34 | BRACKET, TOWING POWER 9AWA-036000 | Skladem | 77,68 Kč | ||
| 35 | LOWER WIRING HOOK 7020-030130 | Skladem | |||
| 36 | HOOK 7020-000190 | Skladem | |||
