Plasty V
| Číslo na výkresu |
Název součástky Kód součástky |
Sklad | Cena | ||
|---|---|---|---|---|---|
| 1 | BOLT KIT M5 6AQV-043003-6000 | Skladem | 29,04 Kč | ||
| 2 | INNER HEX STEPPED SCREW M6x14 6WWV-046602-5000 | Skladem | 15,54 Kč | ||
| 3 | SELF-TAPPING SCREW ST4.2×13 30110-421130010 | Skladem | 29,02 Kč | ||
| 4 | TIE BAND BRACKET, TOOLS KIT A000-030005 | Skladem | 46,61 Kč | ||
| 5 | TIE BAND,BATTERY 6060-150700 | Skladem | 145,20 Kč | ||
| 6 | BATTERY BOX 6AQV-041102-6001 | Skladem | 248,58 Kč | ||
| 7 | NUT CLIP M5 6KM#-040081-8000-M1 | Skladem | 15,54 Kč | ||
| 8 | FRAME SKID PLATE 6AQV-040701-6001 | Není skladem | |||
| 9 | INNER HEX SCREW M6x12 6WWV-046702-5000 | Skladem | 15,54 Kč | ||
| 10 | SIDE PANEL BUSHING 6AQV-040606-7100 | Skladem | 15,54 Kč | ||
| 11 | CLIP NUT ST4.8 8080-000002 | Skladem | 15,54 Kč | ||
| 12 | SELF-TAPPING SCREW ST4.8×13 30110-481130010 | Skladem | 29,02 Kč | ||
| 13 | UPPER GUARD,TAILLIGHT 6AQV-040706-6000 | Skladem | 116,16 Kč | ||
| 14 | STEPPED SCREW M5 6WWV-046502-5000 | Skladem | 15,54 Kč | ||
| 15 | RUBBER 6WWV-045801-5000 | Skladem | 15,54 Kč | ||
| 16 | COVER, REAR ARMREST 6AQV-041401-6000 | Skladem | 246,84 Kč | ||
| 17 | REAR WHEEL FRONT FENDER 6AQV-060402-6000 | Skladem | 101,64 Kč | ||
| 18 | BOLT M6x16 8010-090005 | Skladem | 15,54 Kč | ||
| 19 | SELF-TAPPING SCREW ST4.2×13-C-H 30110-420130070 | Skladem | 29,02 Kč | ||
| 20 | INNER PLATE, REAR FENDER 6AQV-040802-6000 | Skladem | 248,58 Kč | ||
| 21 | REAR LICENSE LIGHT BRACKET 6AQV-040803-6000 | Skladem | 62,15 Kč | ||
| 22 | REAR FENDER 6AQV-040801-6000 | Skladem | 248,58 Kč | ||
| 23 | RUBBER MAT, BATTERY 6AQV-041511-6000 | Skladem | 217,80 Kč | ||
| 24 | HOOK RUBBER, TAIL LIGHT 6WWV-043201-5000 | Skladem | 46,61 Kč | ||
