F04-3 MIDDLE PLASTICS
| Číslo na výkresu |
Název součástky Kód součástky |
Sklad | Cena | ||
|---|---|---|---|---|---|
| 1 | RH FOOT PEDAL 9DRV-042023-1101 | 1 | |||
| 2 | NUT CLIP M6 8030-040800-00001 | Skladem | 15,54 Kč | ||
| 3 | INNER HEX BOLT M6x20 5BWV-040007-5000 | Skladem | 15,54 Kč | ||
| 4 | LH FOOT PEDAL 9DRV-042013-1101 | 1 | |||
| 5 | RH COVER PLATE 9DRV-042024-1101 | 1 | |||
| 6 | LH COVER PLATE 9DRV-042014-1101 | 1 | |||
| 7 | A-CLASP 7DHV-040001-1000 | Skladem | 15,54 Kč | ||
| 8 | LOCK KNOB RUBBER SLEEVE 9NTV-045605-1201 | Skladem | 31,07 Kč | ||
| 9 | LOCK KNOB 9NTV-045602-1201 | 2 | |||
| 10 | RH SIDE PANEL 9DRV-042021-1101-0A400 | 1 | |||
| 10 | RH SIDE PANEL 9DRV-042021-1101-0A500 | 1 | |||
| 11 | LH SIDE PANEL 9DRV-042011-1101-0A400 | 1 | |||
| 11 | LH SIDE PANEL 9DRV-042011-1101-0A500 | 1 | |||
| 12 | INNER HEX BOLT M6x20 5BWV-040008-5000 | Skladem | 15,54 Kč | ||
| 13 | INNER HEX SLEF-TAPPING SCREW ST4.8×16 5BWV-040016-5000 | Skladem | 15,54 Kč | ||
| 14 | CLAMP ST4.8 5020-040049 | Skladem | 15,54 Kč | ||
| 15 | SEAT BASE PLATE 9DRV-041020-1101 | 1 | |||
